Before Fiberglassing
Date/Time: Sun 16 Jul 2006 09:35:07 AM EDT
I cut circles out of foam which which I slid onto rods. The body tubes fit over the foam which makes a handy stand for fiberglassing the body tubes.
Fiberglassing
Date/Time: Sun 16 Jul 2006 10:11:49 AM EDT
Fiberglassing a body tube adds strength to the tube without adding much weight.
Fiberglass Cloth
Date/Time: Sun 16 Jul 2006 10:12:24 AM EDT
I applied a layer of 4oz. fiberglass cloth followed by a layer of 2oz. cloth.
Applying Epoxy
Date/Time: Sun 16 Jul 2006 10:12:50 AM EDT
For the expoxy, I used [misc]West System[/misa] 105 resin with their 206 hardner.
Fins
Date/Time: Sun 16 Jul 2006 11:39:00 AM EDT
The fins and launch lug stand-offs were cut from 1/4" plywood.
Fin Slots
Date/Time: Fri 01 Sep 2006 02:02:45 PM EDT
Slots for the fins and launch lug stand-offs were cut into the body tube using a Dremel rotary tool.
Launch Lugs
Date/Time: Wed 01 Nov 2006 11:43:26 PM EST
The launch lugs are installed on the Upscale Omega.
Close Up of Launch Lug
Date/Time: Wed 01 Nov 2006 11:43:33 PM EST
The launch lugs are installed on stand-offs. Lots of epoxy and a layer of fiberglass ensure they'll stay on.
Omega Fins
Date/Time: Thu 02 Nov 2006 03:53:09 PM EST
Bracha made me these simple fixtures from foam board to help align the fins.
